| Feature |
Detailed Description |
| F/F |
2U |
| Processor |
- Intel® Xeon® processor E5-2600 v4 product family
- Core count: 4, 6, 8, 10, 12, 16, 18, 22 Core
- Processor Cache: 2.5MB per core
|
| Chipset |
Intel C610 series chipset |
| Memory |
Up to 3TB (24 DIMM slots): 4GB/8GB/16GB/32GB/64GB/128GB DDR4 up to 2400MT/s |
| I/O slots |
Up to 7 x PCIe 3.0 slots plus dedicated PERC slot |
| Drive bays |
Internal hard drive bay and hot-plug backplane |
- Up to 16 x 2.5″ HDD: SAS, SATA, nearline SAS SSD: SAS, SATA
- Up to 8 x 3.5″ HDD: SAS, SATA, nearline SAS SSD: SAS, SATAe
|
| Maximum internal storage |
HDD: SAS, SATA, nearline SAS SSD: SAS, SATA
- 16 x 2.5″ – up to 29TB via 1.8TB hot-plug SAS hard drives
- 8 x 3.5″ – up to 64TB via 8TB hot-plug NL SAS hard drives
|
| RAID controllers |
Internal controllers |
PERC S130 (SW RAID), PERC H330, PERC H730, PERC H730P |
| External HBAs (RAID) |
PERC H830 |
| External HBAs (non-RAID) |
12Gbps SAS HBA |
| Embedded NIC |
- 4 x 1Gb
- 2 x 10+2GbE
- 4 x 10GbE NDC
|
| Systems management |
Systems management |
- IPMI 2.0 compliant
- Dell OpenManage Essentials
- Dell OpenManage Mobile
- Dell OpenManage Power Center
|
| Dell OpenManage Integrations: |
- Dell OpenManage Integration Suite for Microsoft® System Center
- Dell OpenManage Integration for VMware® vCenter™
|
| Dell OpenManage Connections |
- HP Operations Manager, IBM Tivoli® Netcool® and CA Network and Systems Management
- Dell OpenManage Plug-in for Oracle® Database Manager
|
| Operating systems |
Operating systems |
- Microsoft Windows Server® 2008/2012 SP2, x86/x64(x64 includes Hyper-V®)
- Microsoft Windows Server 2008/2012 R2, x64 (includes Hyper-V)
- Microsoft Windows HPC Server 2008
- Novell® SUSE® Linux Enterprise Server
- Red Hat® Enterprise Linux
|
| Optional embedded hypervisors |
- Citrix® XenServer®t
- VMware vSphere® ESXi™
|
| Power supply |
- Titanium efficiency 750W AC power supply
- 1100W DC power supply
- Platinum efficiency 495W
- Platinum efficiency 750W
- Platinum efficiency 1100W
|
